Ajax MotionCam white EU motion sensor with camera

malın kodu: 10309.23.WH1

Təsvir Faydalı

Əvvəlki

Növbəti

Yüklə

Техniki xarakteristikalar Ajax MotionCam white EU motion sensor with camera:

Əsas parametrlər

Parametrlərin tam siyahısı

Type	motion sensor
Compatibility	Ajax Hub 2
	Ajax Hub 2 Plus
	Hub Hybrid
	Ajax ReX 2
Radio frequency	868,0−868,6 MHz
	868,7−869,2 MHz
	866,0 – 866,5 МГц
	905,0 – 926,5 МГц
	915,85 – 926,5 МГц
	921,0 – 922,0 МГц
Power supply	batteries /x2 CR123A

Key Features

Type	motion sensor
Compatibility	Ajax Hub 2
	Ajax Hub 2 Plus
	Hub Hybrid
	Ajax ReX 2
Radio frequency	868,0−868,6 MHz
	868,7−869,2 MHz
	866,0 – 866,5 МГц
	905,0 – 926,5 МГц
	915,85 – 926,5 МГц
	921,0 – 922,0 МГц
Horizontal angle of motion detection	88.5 °
Pet immunity to	50 cm (вага: до 20 кг)
Motion detection range	12 m
Wireless transmission range	1700 m
Vertical angle of motion detection	80°
Photo resolution	640 × 480 pix. 320 × 240 пікселів (за початкових налаштувань)

Additional information

Power supply	batteries /x2 CR123A
Operating humidity	up to 75%
Operating temperature	-10-40 °C
Relative humidity measurement range	Рекоменд %
Radio signal power	20 mW
Radio modulation	GFSK
Additional information	two-way communication between devices
	защита от саботажа
	мгновенные оповещения
	дистанционная настройка в приложениях Ajax
	блочное шифрование с плавающим ключом
Package Contents	motion sensor
	SmartBracket mounting panel
	mounting kit
	батарейка CR123A
	инструкция

Physical

Dimensions	135 × 70 × 60 mm
Colour	white
Weight	167 g

Qablaşdırma parametrləri

Eni	80 mm
Hündürlüyü	70 mm
Uzunluğu	140 mm
Çəkisi	0.22 kq
Həcmi	0.0008 m3

Zəmanət

24 ay

MotionCam white EU Motion sensor with Ajax camera with PIR sensor, motion detection range: 12 m. MotionCam will capture intruders even in complete darkness, thanks to the IR backlight.

230 AZN*

mövcud deyil

* Tövsiyə edilən pərakəndə qiymət

Təsvir Ajax MotionCam white EU motion sensor with camera

Intellect against false alarms

We have combined special optics with a software filter for false alarms in motion detectors. Along with a professional installation, it gives high detection accuracy.

Special lens

The pattern of the Fresnel lens sections is designed so that the diagrams of the infrared radiation of a human, an animal, and thermal noise have significant differences. Large sections of the lens capture radiation at the level of the head and torso of an adult. Smaller sections make the diagram more detailed. The MotionCam Jeweller lens provides the detector with accurate information about the thermal object in the detection zone and the nature of its movement.

Professional installation

Installing the MotionCam Jeweller in the right spot, at the optimum height, and perpendicular to the likely intrusion path ensures an informative thermal diagram. It significantly improves detection accuracy. Professional installation also makes the pet immunity feature more effective.

Filter for thermal interferences

The detector instantly analyzes the thermal diagram from the sensor: the infrared radiation intensity, the heat spot size, the motion speed, the time spent in the detection zone, and other parameters.

Ajax engineers have analyzed thousands of IR sensor triggerings caused by humans, animals, and thermal interference and developed SmartDetect. The software algorithm finds false alarm markers instantly and with high accuracy. As a result, the detector accurately responds to a human and does not bother the user with false alarms.

Temperature compensation

Temperature compensation is a software mechanism keeping the thermal diagram contrast even if the ambient temperature is close to the temperature of the human body.

With each ambient temperature measurement, the detector corrects the PIR sensor data according to the coefficient table stored in its memory. The detector is effective over the entire operating temperature range.

Sensitivity level

With the sensitivity setting, the detector adapts to the conditions of a particular room, considering possible thermal interference or pets. Changing the sensitivity setting affects the markers by which false alarms are filtered.

With low sensitivity, the detector is less likely to respond even to an active pet. And with high sensitivity, it will raise the alarm in case of any motion in the detection zone.

Sensitivity is configured in the Ajax app both on-site and remotely.

More than a photo. Faster than a video.

MotionCam Jeweller will show the actual situation from the scene even before the burglars understand that they’re busted. An animated series of photos follows the instant alarm for an accurate situation appraisal. MotionCam Jeweller can only take photos in case of an alarm. The detector software architecture does not support taking a photo on demand.

Less concern

Up to 70% of false alarms happen when disarming the security system. With MotionCam, system users and monitoring company operators can verify in seconds whether an alarm is real and respond accordingly.

More security

Both system users and a rapid response team need to clearly understand what happens on the scene in case of an alarm. MotionCam will show how many intruders are armed and whether they are still in the room. This will help a security company patrol prepare, and the users avoid danger.

Evidence in a smartphone

A series of animated photos provide the law enforcers with the description of intruders, no time wasted. MotionCam will capture them even in complete darkness, thanks to the IR backlight. The chances of catching burglars in the act increase.
